Model No.︰CPCD300

Brand Name︰Silon

Country of Origin︰China

Unit Price︰CNY ¥ 1230000 / unit

Minimum Order︰1 unit

Inquire Now

Product Description

 Main Technical Characteristics of the CPCD300 Diesel Forklift

  • Engine:Donfeng Cummins Engine 6BTAA5.9-C190,low oil consumption,high quality turbocharged enine,good power performance,big torque reserves,has strong power,energy conservation and environmental protectin
  • Steering axleadopt transverse oil cylinder type steering bridge,full-hyfraulic steering,flexible and light,reliable
  • Transmission&torque converter:imported technology,reliable performane,convenient maintenance,smooth transmission,and convenient operation
  • Control system:pilot valve cntrol device to make the work efficiency and reduce drivers labor intensity
  • Hydraulic sytem:double pump confluence,smal system flow,low power consumption,reliable performance,excellet operating perforrmance
  • Pipeline:high pressure oil line use the first brand Parker Oil Tube,impact resistance,wear resistance and long service lift
  • Tyre:sino-us joint brand,resistant to wear and sting,high strength tyres,bear heavy loaded-safe and reliable
  • Fork:use Cascade fork,higher strength,more weaproof,highly increase the service life
  • Mast:box-type internal-external mast,special all-round roller bearings,increase lifting performance
  • Cab:with cooling and heating air-conditioning,and rupture membrane,explosion proof,heat insulation,prevent glare,sound insulation.Damping luxury cab with sunroof,wid view and comfortable seats,flexible control.

Technical Parameter  of the HNF300 Diesel Forklift

Parameter Model   CPCD300
Load capacity Kg 30000
Weight Kg 37550
Max. lifting height mm 3000
Load center mm 1250
Lifting speed with load mm/s 290
Tilt angle (front/back) deg. 6/12
Travel Max. traveling speed Km/h 28
Min. turning radius mm 8500
Min. ground clearance mm 350
Gradeability with load % 20
Overall length mm General use – 8675
Overall width mm 3000
Overall height mm 3850
Fork size (L*W*H) mm General use – 2000*330*120
Wheel base mm 4100
Tread (front) mm 2160
Tread (rear) mm 2150
Engine Model   WD10G240E21
Rated power/rotate speed KW/rpm 175/2200
Max. torque/rotate speed N.m/rpm 1000/1600
Tires type Front   4x14.00-24-28PR
Rear   2x14.00-24-28PR

Payment Terms︰ 30% Deposit and 70% Before shipment to Shanghai Seaport
